UNEX Trunking

UNEX Trunking

Active filters

  • Unex divider for trunking 60mm in U23X

    To separate circuits. Length: 3m. Insulating material. Removable, with...
    View Product
    To separate circuits. Length: 3m. Insulating material. Removable, with frontal mounting and solid fixing to the base. Protection against mechanical damage IK08.
  • NEW Unex C-shape cover for HVAC 35x35 in U23X

    For fixing and connecting pipes in split type air conditioning systems. To...
    View Product
    For fixing and connecting pipes in split type air conditioning systems. To be used with the Pipe clamp 31130-04. Rectilinear design that integrates with the construction elements, giving the system a nice finishing. Paintable. Film protected. Suitable for outdoor use. Its rigidity ensures good anchoring to the base and prevents deformations. length: 2m
  • Unex trunking 30x40 in U23X

    For distribution. Suitable for outdoor use. Complete range with all...
    View Product
    For distribution. Suitable for outdoor use. Complete range with all necessary fittings, available in white and grey. Homogeneity with the rest of the installation's elements. 1 cable retainer every 0,5m is included. Length: 3m. Grey. Safety: electrical (insulating material, IP4X mounted on wall); mechanical (protection against impacts IK08); and in front of fire (glow-wire test at 960 Deg C; non-flame propagator). Easy mounting. The cover is pressure mounted (no need to slide it). The cable retainer retains the cables and allows for independent access to each circuit. Homogeneity of colours between the trunking and the fittings. Can be painted. Removable divider, pressure mounted.
  • NEW Unex C-shape cover for HVAC 45x75 in U23X

    For fixing and connecting pipes in split type air conditioning systems. To...
    View Product
    For fixing and connecting pipes in split type air conditioning systems. To be used with the detachable strip 31075-04 or with the single base plate 31175-04, or with the combination of both. Rectilinear design that integrates with the construction elements, giving the system a nice finishing. Paintable. Film protected. Suitable for outdoor use. Its rigidity ensures good anchoring to the base and prevents deformations. length: 2m
  • Unex adapter for 2 outlets Mosaic type, cover 65mm, aluminium colour, in U24X

    To mount Mosaic switches and socket outlets (4 modules 22,5x45). Aluminium...
    View Product
    To mount Mosaic switches and socket outlets (4 modules 22,5x45). Aluminium colour. Insulating material. Easy mounting. Protection against mechanical damage IK08.
  • Unex trunking 40x40 in U23X

    For distribution. Suitable for outdoor use. Complete range with all...
    View Product
    For distribution. Suitable for outdoor use. Complete range with all necessary fittings, available in white and grey. Homogeneity with the rest of the installation's elements. 1 cable retainer every 0,5m is included. Length: 3m. Grey. Safety: electrical (insulating material, IP4X mounted on wall); mechanical (protection against impacts IK10); and in front of fire (glow-wire test at 960 Deg C; non-flame propagator). Easy mounting. The cover is pressure mounted (no need to slide it). The cable retainer retains the cables and allows for independent access to each circuit. Homogeneity of colours between the trunking and the fittings. Can be painted. Removable divider, pressure mounted.
  • Unex 1 cover trunking 50X80 (65 mm cover) in U23X

    Designed to fit in the most demanding architectural and decorative...
    View Product
    Designed to fit in the most demanding architectural and decorative surroundings. Possibility to attach or flush-mount in walls and furniture. 1 Internal lid. Possible sub-divisions with a removable divider. Perforated base every 250mm. Length: 2m. Aluminium colour. Safety: electrical (insulating material, IP4X); mechanical (protection against impacts IK07); and in front of fire (glow-wire test at 960 Deg C; non-flame propagator). Free choice and composition of the most common switches and sockets, with flexibility to combine them in unlimited number. Easy mounting: The cover is pressure mounted and removable by means of a tool. Easy integration with other construction elements (furniture, screens. . . ). Homogeneity of colours between trunking, fittings and adapters. Can be painted. Protective film.
  • NEW Unex C-shape cover for HVAC 60x75 in U23X

    For fixing and connecting pipes in split type air conditioning systems. To...
    View Product
    For fixing and connecting pipes in split type air conditioning systems. To be used with the detachable strip 31075-04 or with the single base plate 31175-04, or with the combination of both. Rectilinear design that integrates with the construction elements, giving the system a nice finishing. Paintable. Film protected. Suitable for outdoor use. Its rigidity ensures good anchoring to the base and prevents deformations. length: 2m
  • NEW DESIGN Unex trunking 40x60 in U23X

    Profile for cable distribution with external cover, suitable for outdoor use....
    View Product
    Profile for cable distribution with external cover, suitable for outdoor use. It has flexible compartmentation for the conduction and protection of electrical and communication cables. The base is perforated every 250mm. With the trunking are supplied, a retainer every 0. 5m and two junctions. These parts come pre-assembled. Length: 3m. Safety: mechanical (impact protection IK10), electrical (insulating material, IP4X mounted on the wall) and in case of fire (incandescent wire test at 960 Deg C, no flame propagator). The cover assembly is made under pressure (it is not necessary to slide to mount it). The retainer keeps the cables in place ensuring the fixing of the cover in the most demanding cases. The junctions mechanically join two sections of trunking guaranteeing its perfect alignment, facilitating the assembly and fixing of the bases on the surface. Both the trunking and the finishing elements can be painted. Mobile divider with front mounting. Colour: grey RAL 7035.
  • Unex 1 cover trunking 50x100 (80 mm cover) in U23X

    Designed to fit in the most demanding architectural and decorative...
    View Product
    Designed to fit in the most demanding architectural and decorative surroundings. Possibility to attach or flush-mount in walls and furniture. 1 Internal lid. Possible sub-divisions with a removable divider. Perforated base every 250mm. Length: 2m. Aluminium colour. Safety: electrical (insulating material, IP4X); mechanical (protection against impacts IK07); and in front of fire (glow-wire test at 960 Deg C; non-flame propagator). Free choice and composition of the most common switches and sockets, with flexibility to combine them in unlimited number. Easy mounting: The cover is pressure mounted and removable by means of a tool. Easy integration with other construction elements (furniture, screens. . . ). Homogeneity of colours between trunking, fittings and adapters. Can be painted. Protective film.
  • NEW Unex C-shape cover HVAC 60x100 in U23X

    For fixing and connecting pipes in split type air conditioning systems. To...
    View Product
    For fixing and connecting pipes in split type air conditioning systems. To be used with the detachable strip 31100-04 or with the single base plate 31101-04, or with the combination of both. Rectilinear design that integrates with the construction elements, giving the system a nice finishing. Paintable. Film protected. Suitable for outdoor use. Its rigidity ensures good anchoring to the base and prevents deformations. length: 2m
  • Unex trunking for HVAC 30x40 in U23X

    For conduction and neat finishing of Air Conditioning installations with...
    View Product
    For conduction and neat finishing of Air Conditioning installations with split-type equipment. Suitable for outdoor use. 1 pre-mounted cable retainer included every 0,5m. Perforated base every 250mm. Length: 2m. White. Fire safety: Glow-wire test at 960 Deg C; non-flame propagator. Easy mounting and maintenance. The cover is easy to mount and remove, providing a very safe fixing. Cost reduction and safe use:Without cutting tips or edges. Flexible, resistant and rounded prongs, avoiding damage to cables and personal injury. Slots until 6mm2 for cable derivation.
