LEDDL - DIMMABLE DEEP RECESSED LED DOWNLIGHTS

LEDDL - DIMMABLE DEEP RECESSED LED DOWNLIGHTS

The commercial LED downlight range covers most requirements for office, classroom and retail applications. These downlights are extremely robust, reliable and come with a dimmable driver enhancing efficiency.


LEDDL
Description

The commercial LED downlight range covers most requirements for office, classroom and retail applications. These downlights are extremely robust, reliable and come with a dimmable driver enhancing efficiency.
This downlight is an ideal replacement for 150W metal halide downlights in high-mounting ceilings.



FEATURES

  • Reduce Energy Costs by up to 50%
  • External dimmable driver (1-10V)
  • Three Year Limited Warranty
  • Comes with a secondary suspension mounting wire for enhanced safety

TECHNICAL SPECIFICATIONS

CAT No.
LEDDL175-70ACLEDDL210-70ACLEDDL260-38NW-WHITE
Power Consumption 70W 38
Input Voltage/Output Current 200-240V AC, 50/60Hz
Fixture Lumens 5132lm (4000K) 3228lm (4000K)
LED Lighting Efficiency 75lm/W
Colour Temperature Natural White 4000K
Pure White 5000K
Cool White 6000K
Colour Rendering Ra>85
Power Factor >0.95
IP Rating IP20
Lifespan 35,000 hours
LED CITIZEN LM80, L70
Eco-friendly ROHS
Materials Oxidised Aluminium, Glass
Beam Angle 50° 45°
Driver Dimmable (1-10V)
Dimensions 190mm Faceplate, 175mm Cutout 230mm Faceplate, 210mm Cutout 280mm Faceplate, 260mm Cutout


















Add suffix: PW=Pure white
                NW=Natural white

LEDDL
