Floor Outlet Box 2 x 10amp Auto Swiched Outlets 3 x Data Provisions - Stainless Steel Ressessed (19mm) 245 Series (Shallow)

Floor Outlet Box 2 x 10amp Auto Swiched Outlets 3 x Data Provisions - Stainless Steel Ressessed (19mm) 245 Series (Shallow)

$455.40
Tax included

The FB245SS19R2P3DS50 floor outlet box comes complete with a height-adjustable stainless steel 19mm Ressessed lid and provision for 2x 10-amp auto-switched outlets and 3 data provisions.







FB245SS19R2P3DS50
Quantity



Secure Payments are easier than ever! Stripe's payment solutions



Delivery Option’s, you choose from our list of delivery partners



Manufactures warranty on all Cableaway sold products.

The FB245SS19R2P3DS50 floor outlet box comes complete with a height-adjustable stainless steel 19mm recessed lid, 2 x 10 amp auto switched outlets and provision for 3 x data. At an overall height of just 74mm including the lid, this shallow carcass design is ideal for applications with limited sub-floor depth.

TECHNICAL SPECIFICATIONS

Part Number FB245SS19R2P3DS50
Lid Type Recessed Square Edge Finish Lid Section
Lid Finish Stainless Steel Finish
Carcass Type Shallow Depth Carcass Box
Body Material Powder coated zinc annealed steel
Frame & Lid Material Stainless steel
Power Outlet Capacity 2 x 10 Amp Auto Switched Power Outlets
Data Outlet Capacity 3 x Data Outlet Provisions
Conduit Knockouts 25mm knockouts

DIMENSIONS

BOX WIDTH
125 mm
BOX LENGTH
225 mm
BOX DEPTH
52 mm
DEPTH INCL. LID
74 mm
LID WIDTH
150 mm
LID LENGTH
250 mm

KEY FEATURES

  • ● Floor box body manufactured from powder coated zinc annealed steel
  • ● 25mm knockouts provided for easy conduit entry
  • ● Frame and lid manufactured from stainless steel
  • ● 10 amp auto switched power outlets supplied
  • ● Provision for data outlets
  • ● Shallow 52mm carcass for reduced sub-floor depth

TYPICAL APPLICATIONS

Commercial offices & open plan workspaces
Conference rooms & boardrooms
Retail & showroom fit-outs
Hospitality & hotels
Educational facilities
Residential installations

ORDERING INFORMATION

Part Number FB245SS19R2P3DS50
Series 245 Series
Weight 4.0 kg
Warranty Manufacturer's warranty
FB245SS19R2P3DS50

Data sheet

FLOOR BOX LID TYPE
FLUSH FINISH LID SECTION
FLOOR BOX LID FINISH TYPE
STAINLESS STEEL FINISH
FLOOR BOX CARCASS TYPE
STANDARD DEPTH CARCASS BOX
POWER OUTLET CAPACITY
1 - STANDARD DGPO OUTLET
