4 Power 4 Data Shallow Stainless Steel (Square Edge) Flush Floor Outlet Box

Shallow Floor Box with Stainless Steel Square Edge Flush lid complete with 4 x power 4 x Data 54mm Shallow Carcass

$523.99
Tax included

At an overall height of just 54mm the FBSSF4P4DS50-SE floor outlet box contains 4 x autoswitched outlets and the provision for 4 x data is remarkably clever in design.

FBSSF4P4DS50-SE
Quantity



Secure Payments are easier than ever! Stripe's payment solutions



Delivery Option’s, you choose from our list of delivery partners



Manufactures warranty on all Cableaway sold products.

At an overall height of just 54mm, the FBSSF4P4DS50-SE shallow floor outlet box comes complete with a height-adjustable stainless steel (square edge) flush lid, 4 x single auto switched outlets and provision for 4 x data mechs (mechs by others).

TECHNICAL SPECIFICATIONS

Part Number FBSSF4P4DS50-SE
Lid Type Flush, Square Edge
Lid Finish Stainless Steel (Square Edge)
Carcass Type Shallow Depth (50mm)
Outlet Configuration 4 x Single Auto Switched Outlets + Provision for 4 x Data
Body Material Powder Coated Zinc Anneal Steel
Frame & Lid Material Stainless Steel (Square Edge)
Conduit Knockouts 20mm & 25mm
Weight 4.0 kg (approx.)

DIMENSIONS

LID WIDTH
220 mm
LID LENGTH
250 mm
CARCASS WIDTH
194 mm
CARCASS LENGTH
227 mm
CARCASS DEPTH
50 mm
DEPTH TO UNDERSIDE OF LID
54 mm

KEY FEATURES

  • ● Height-adjustable stainless steel flush lid with a square edge profile
  • ● Ultra-shallow 50mm carcass depth, ideal for low-clearance floors
  • ● Powder coated zinc anneal steel body for durability and corrosion resistance
  • ● Frame and lid manufactured from stainless steel
  • ● 20mm and 25mm knockouts provided for easy conduit entry
  • ● 4 x single auto switched power outlets supplied
  • ● Provision for 4 x data mechs (mechs by others)
  • ● Range of accessory plates available

TYPICAL APPLICATIONS

Commercial offices & open plan workspaces
Conference rooms & boardrooms
Retail & showroom fit-outs
Hospitality & hotels
Educational facilities
Residential installations

ORDERING INFORMATION

Part Number FBSSF4P4DS50-SE
Series Shallow Floor Outlet Box Series (Square Flush Lid, Power & Data)
Warranty Manufacturer's warranty
FBSSF4P4DS50-SE

Data sheet

FLOOR BOX LID TYPE
FLUSH SQUARE EDGE FINISH LID SECTION
FLOOR BOX LID FINISH TYPE
STAINLESS STEEL FINISH
FLOOR BOX CARCASS TYPE
SHALLOW DEPTH CARCASS BOX
POWER OUTLET CAPACITY
1 - 4 SINGLE AUTO SWITCHED POWER OUTLETS
DATA OUTLET CAPACITY
1 - 4 DATA OUTLET PROVISIONS
