Cableaway's Brass Flush Lid Floor Outlet Boxes bring a premium finish to flush-mounted floor power and data outlets, suited to hospitality, retail, and architectural fit-outs where a brass finish complements the surrounding décor.
The range spans the compact 145 Series — available in standard and round flush styles, with single and double GPO configurations and USB-A/USB-C charging options — through to the full-size brass flush lid range with 2 to 6 power outlets and 4 to 10 data provisions. Standard depth and Shallow (50mm) carcass options are both available, and a 19mm brass recessed lid option is also offered within the 145 Series for applications needing tile or timber infill rather than a fully flush finish.
All brass flush lid boxes feature a powder coated zinc annealed steel body with a brass frame and lid, height-adjustable brackets to accommodate changes in finished floor level, and cable exit provisions for a clean, trip-hazard-free installation.
Showing 1-12 of 27 item(s)
Showing 1-12 of 27 item(s)
The FB145BRF2P3D floor outlet box has a brass flush lid and 2 x 10 A auto switched outlets and provision for 3 x data. Finished height 105 mm, adjustable to 130 mm on the adjustable mounting bracket.

The FB145BRF1STDOUSB floor outlet box has a brass flush lid and 1 x standard double GPO with USB-A and USB-C charging. Finished height 105 mm, adjustable to 130 mm on the adjustable mounting bracket.

The FB145BRF2PS65 shallow floor outlet box has a brass flush lid and 2 x 10 A auto switched outlets. Finished height 67 mm, adjustable to 92 mm on the adjustable mounting bracket.

The FB145BRF1STDO floor outlet box has a brass flush lid and 1 x standard double GPO. Finished height 105 mm, adjustable to 130 mm on the adjustable mounting bracket.

The FB145CBRF1STDOUSB floor outlet box has a brass round flush lid and 1 x standard double GPO with USB-A and USB-C charging. Finished height 105 mm, adjustable to 130 mm on the adjustable mounting bracket.

The FB145CBRF2PS65 shallow floor outlet box has a brass round flush lid and 2 x 10 A auto switched outlets. Finished height 67 mm, adjustable to 92 mm on the adjustable mounting bracket.

The FB145CBRF2P3D floor outlet box has a brass round flush lid and 2 x 10 A auto switched outlets and provision for 3 x data. Finished height 105 mm, adjustable to 130 mm on the adjustable mounting bracket.

The FB145CBRF1STDO floor outlet box has a brass round flush lid and 1 x standard double GPO. Finished height 105 mm, adjustable to 130 mm on the adjustable mounting bracket.

The FBBRF2P4D floor outlet box has a brass flush lid and 2 x 10 A auto switched outlets and provision for 4 x data. Finished height 94 mm, adjustable to 119 mm on the adjustable mounting bracket.

The FBBRF2P8D floor outlet box has a brass flush lid and 2 x 10 A auto switched outlets and provision for 8 x data. Finished height 94 mm, adjustable to 119 mm on the adjustable mounting bracket.

The FBBRF2P10D floor outlet box has a brass flush lid and 2 x 10 A auto switched outlets and provision for 10 x data. Finished height 94 mm, adjustable to 119 mm on the adjustable mounting bracket.

The FBBRF4P4D floor outlet box has a brass flush lid and 4 x 10 A auto switched outlets and provision for 4 x data. Finished height 94 mm, adjustable to 119 mm on the adjustable mounting bracket.
