60 X 200mm DROP IN LID SECTION (Black)

60 X 200mm DROP IN LID SECTION (Pearl White)

60mm x 200mm skirting duct Drop in lid section. 1.2m Length Pearl White finish.

MANUFACTURE TO ORDER



SDDL200W


Secure Payments are easier than ever! Stripe's payment solutions



Delivery Option’s, you choose from our list of delivery partners



Manufacturer's warranty on all Cableaway sold products.

The SDDL200W is the drop-in lid section for Cableaway's 60mm x 200mm SD Series aluminium skirting duct in a Pearl White finish, supplied in 1.2m lengths. It drops into the duct body channel to conceal and protect power and data cabling, and can be lifted out for easy access when cables need to be added or serviced.

TECHNICAL SPECIFICATIONS

Component Drop-In Lid Section
Suits Duct Size 60mm x 200mm
Standard Length 1.2m
Material Aluminium extrusion
Finish Pearl White
Fitting Style Drop-in, removable for cable access
Compatible Body Matching SD Series duct body, sold separately

KEY FEATURES

● Drops into duct body channel for a clean, concealed finish
● Removable for fast access to cabling
● Matches Cableaway's SD Series skirting duct body profile
● Available in Pearl White to suit matching duct finish
● Part of Cableaway's SD Series aluminium skirting duct system

TYPICAL APPLICATIONS

● Commercial Office Fit-Outs ● Small to Medium Projects
● Home Office Cable Management ● Retail and Hospitality Fit-Outs
● Reticulation of Power & Data Cabling ● Data, AV & Multimedia Outlet Housing

ORDERING INFORMATION

Part Number SDDL200W
Series SD Series Aluminium Skirting Duct
Warranty Manufacturer's warranty

COMPLIANCE & INSTALLATION

Installation To be installed in accordance with AS/NZS 3000 (Wiring Rules) and all relevant Australian electrical standards
Electrical work Power outlets, data outlets and all wiring must be installed by a licensed electrician
Earthing Metal skirting duct and service columns must be earthed in accordance with AS/NZS 3000
