Spacepole Series - Vertical Columns
$0.00
Tax included
The ESPC Space Pole from Cableaway is a versatile aluminium service column designed to deliver power, data, and communication services from the ceiling to workstations. Manufactured from high-quality extruded aluminium, it provides a strong yet lightweight solution for commercial, retail, and office environments. The design allows for efficient cable routing and service segregation while maintaining a clean, professional appearance. Available in a range of lengths and finishes, it integrates with various outlet and accessory options to suit project requirements. Ideal for new installations and fit-outs, the ESPC Space Pole offers a practical and flexible cable management solution.
Secure Payments are easier than ever! Stripe's payment solutions
Delivery Option’s, you choose from our list of delivery partners
Manufactures warranty on all Cableaway sold products.
The ESPC Space Pole from Cableaway is a versatile aluminium service column that delivers power, data and communication services from open ceiling space directly to workstations — without wall chasing or floor trenching. Manufactured from high-quality extruded aluminium, it provides a strong yet lightweight solution for commercial, retail and office environments, with efficient cable routing and service segregation behind a clean, professional profile.
Specifications
| Part number range | ESPC-SERIES |
| Available lengths | 2.8m, 3.3m, 4.0m |
| Configuration | Vertical & horizontal service column / ducting |
| Material | Extruded aluminium |
| Standard finishes | Black (BL), Natural Anodised (NA), Opal Grey (OG), Off White (OW) |
| Custom finishes | Standard powder-coated finishes available on request |
| Included | Floor mounting kit, ceiling (T-Bar) mount, three wall plate accessory mounting kits |
Key Features
- ●Extruded aluminium — lightweight, strong, corrosion-resistant
- ●Supplied completely boxed with floor mounting kit and ceiling (T-Bar) mount
- ●Three standard wall plate accessory mounting kits included (extras available)
- ●Available in three standard lengths — 2.8m, 3.3m or 4.0m
- ●Four standard finishes, plus any standard powder-coated finish on request
- ●Full accessory range for mounting, joining and internal cable division
Typical Applications
|
Open-plan offices and workstations
|
Classrooms and university laboratories
|
|
Retail showrooms and factory floors
|
New installations and fit-outs
|
Ordering Information — Part Number
| ESPC28-XX | 2.8m length |
| ESPC33-XX | 3.3m length |
| ESPC40-XX | 4.0m length |
| XX = Colour code | BL / NA / OG / OW — refer to colour code when ordering |
Accessories
| ESPCMB | Accessory mounting box (84mm centres) |
| ESPCF | Ceiling mounting flange |
| ESPCCF2 | Double ceiling flange (back-to-back mounting cover) |
| ESPCFB | Concrete/timber floor mounting kit |
| ESPCCK | T-Bar internal ceiling mounting kit |
| AOL45-80JP | Joining pins (pack of 4) |
| Z21AO54 | Plastic 2-channel divider (600mm section) |
Custom heights and finishes available on request — call 1300 883 452 or email sales@cableaway.com.au.
ESPC - SERIES
