Unex Trunking 31

Unex Trunking 31

Active filters

  • NEW Unex C-shape cover HVAC 60x100 in U23X

    For fixing and connecting pipes in split type air conditioning systems. To...
    View Product
    For fixing and connecting pipes in split type air conditioning systems. To be used with the detachable strip 31100-04 or with the single base plate 31101-04, or with the combination of both. Rectilinear design that integrates with the construction elements, giving the system a nice finishing. Paintable. Film protected. Suitable for outdoor use. Its rigidity ensures good anchoring to the base and prevents deformations. length: 2m
  • NEW Unex internal angle for HVAC 60x100 in U24X

    To cover and protect pipes in the inner corners of split type air...
    View Product
    To cover and protect pipes in the inner corners of split type air conditioning systems. Robust, single piece design, assembled above the cover, covering its cuts. Greater length of the fittings to better adapt to the cover and absorb the wall unevenness. Fittings with bending radius suitable for the laying of the pipes that guarantee a correct function of theinstallation. Isulating material. Ease of installation. Colour: White RAL 9010
  • NEW Unex Detachable strip for HVAC in U23X for 100mm high cover

    Detachable Strip for fixing and connecting pipes in split type air...
    View Product
    Detachable Strip for fixing and connecting pipes in split type air conditioning systems. To be used with the Unex c-shape cover Part no. 31033-02. Innovative design that facilitates the handling of pipes and speeds up the air conditioning system assembly process. Solid mounting bases that make the system more secure. Possibility of choosing the most suitable Unex cable tie dimension, up to 7. 6 mm width, ensuring theanchoring of pipes and cables. The base slots allow new cable ties to be placed without disassembling material already installed. The fastening of pipes and cables is completely independent. length: 2m
  • NEW Unex Wall duct 60x100 in U24X

    Covers and protects the pipes in air conditioning installations with split...
    View Product
    Covers and protects the pipes in air conditioning installations with split type devices when crossing the wall. It can be done at any point of the installation. Robust, single piece design, assembled above the cover, covering its cuts. Greater length of the finishing elements to adapt better to the cover, absorb irregularities of the wall and hide possible errors in the cut of the trunking. Colour: White RAL 9010
  • NEW Unex single base plate for HVAC in U23X for 75mm high cover

    Single base plate for fixing and connecting pipes in split type air...
    View Product
    Single base plate for fixing and connecting pipes in split type air conditioning systems. To be used with the Unex c-shape cover Part no. 31021-02 and 31032-02. Innovative design that facilitates the handling of pipes and speeds up the air conditioning system assembly process. Solid mounting bases that make the system more secure. Possibility of choosing the most suitable Unex cable tie dimension, up to 7. 6 mm width, ensuring theanchoring of pipes and cables. The base slots allow new cable ties to be placed without disassembling material already installed. The fastening of pipes and cables is completely independent. A solid piece for each cover width, which ensures system robustness. No need to alter or cut the base to install it. Fast assembly, because the base is directly positioned on the wall following the straight level line marked previously on the wall. Single base plate dimensions: 47mm.
  • NEW Unex Pipe clamp 35x35 in U24X

    To tie drain pipes together in HVAC installations. It also works with...
    View Product
    To tie drain pipes together in HVAC installations. It also works with electric, water and sanitary pipes. It can be used as base and can be mounted with the C-shape cover part number 31010-02. The diameter of the pipes must be between 16 and 20 mm. Easy and quick to assemble and fix. Suitable for outdoor installations. Colour: grey RAL 7035
  • NEW Unex end cover for HVAC 60x100 in U24X

    To cover the ends of the installation. End cover with screws allowing a safe...
    View Product
    To cover the ends of the installation. End cover with screws allowing a safe assembly in any position. Mounting above the cover, covering its cuts. Colour: White RAL 9010
  • NEW Unex flat angle for HVAC 60x100 in U24X

    To cover and protect pipes in the 90 Deg changes of direction of split type...
    View Product
    To cover and protect pipes in the 90 Deg changes of direction of split type air conditioning systems. Robust, single piece design, assembled above the cover, covering its cuts. Greater length of the fittings to better adapt to the cover and absorb the wall unevenness. Fittings with bending radius suitable for the laying of the pipes that guarantee a correct function of theinstallation. Insulating material. Ease installation of pipes and cables. Colour: White RAL 9010
  • NEW Unex Joint cover piece 60x100 in U24X

    Covers and protects the pipes in air conditioning systems with split type...
    View Product
    Covers and protects the pipes in air conditioning systems with split type devices when joining two lengths of cover. It can be done at any point of the installation. Robust, single piece design, assembled above the cover, covering its cuts. Greater length of the finishing elements to adapt better to the cover, absorb irregularities of the wall and hide possible errors in the cut of the trunking. Colour: White RAL 9010
  • NEW Unex T-joint 60x100 in U24X

    Covers and protects the pipes in air conditioning systems with Split 2x1 type...
    View Product
    Covers and protects the pipes in air conditioning systems with Split 2x1 type devices when derivations are made. It can be done at any point of the installation. Robust, single piece design, assembled above the cover, covering its cuts. Greater length of the finishing elements to adapt better to the cover, absorb irregularities of the wall and hide possible errors in the cut of the trunking. Colour: White RAL 9010
  • NEW Unex external angle for HVAC 60x100 in U24X

    To cover and protect pipes in the outer corners of split type air...
    View Product
    To cover and protect pipes in the outer corners of split type air conditioning systems. Robust, single piece design, assembled above the cover, covering its cuts. Greater length of the fittings to better adapt to the cover and absorb the wall unevenness. Isulating material. Ease of installation. Colour: White RAL 9010
  • NEW Unex Wall bend duct 60x100 in U24X

    It covers and protects the pipes when crossing the wall in a corner in air...
    View Product
    It covers and protects the pipes when crossing the wall in a corner in air conditioning installations with split type appliances. Robust, single piece design, assembled above the cover, covering its cuts. Greater length of the finishing elements to adapt better to the cover, absorb irregularities of the wall and hide possible errors in the cut of the trunking. Colour: White RAL 9010
