Trunking

Trunking

Subcategories

Active filters

  • Unex divider for trunking 60mm in U23X

    To separate circuits. Length: 3m. Insulating material. Removable, with...
    View Product
    To separate circuits. Length: 3m. Insulating material. Removable, with frontal mounting and solid fixing to the base. Protection against mechanical damage IK08.
  • NEW DESIGN Unex trunking 60x230 in U23X

    Profile for cable distribution with external cover, suitable for outdoor use....
    View Product
    Profile for cable distribution with external cover, suitable for outdoor use. It has flexible compartmentation for the conduction and protection of electrical and communication cables. The base is perforated every 250mm. With the trunking are supplied, a retainer every 0. 5m and two junctions. These parts come pre-assembled. Length: 3m. Safety: mechanical (impact protection IK10), electrical (insulating material, IP4X mounted on the wall) and in case of fire (incandescent wire test at 960 Deg C, no flame propagator). The cover assembly is made under pressure (it is not necessary to slide to mount it). The retainer keeps the cables in place ensuring the fixing of the cover in the most demanding cases. The junctions mechanically join two sections of trunking guaranteeing its perfect alignment, facilitating the assembly and fixing of the bases on the surface. Both the trunking and the finishing elements can be painted. Mobile divider with front mounting. Colour: grey RAL 7035.
  • Unex divider for trunking 40mm in U23X

    To separate circuits. Length: 3m. Insulating material. Removable, with...
    View Product
    To separate circuits. Length: 3m. Insulating material. Removable, with frontal mounting and solid fixing to the base. Protection against mechanical damage IK08.
  • NEW DESIGN Unex trunking 60x190 in U23X

    Profile for cable distribution with external cover, suitable for outdoor use....
    View Product
    Profile for cable distribution with external cover, suitable for outdoor use. It has flexible compartmentation for the conduction and protection of electrical and communication cables. The base is perforated every 250mm. With the trunking are supplied, a retainer every 0. 5m and two junctions. These parts come pre-assembled. Length: 3m. Safety: mechanical (impact protection IK10), electrical (insulating material, IP4X mounted on the wall) and in case of fire (incandescent wire test at 960 Deg C, no flame propagator). The cover assembly is made under pressure (it is not necessary to slide to mount it). The retainer keeps the cables in place ensuring the fixing of the cover in the most demanding cases. The junctions mechanically join two sections of trunking guaranteeing its perfect alignment, facilitating the assembly and fixing of the bases on the surface. Both the trunking and the finishing elements can be painted. Mobile divider with front mounting. Colour: grey RAL 7035.
  • NEW DESIGN Unex trunking 60x150 in U23X

    Profile for cable distribution with external cover, suitable for outdoor use....
    View Product
    Profile for cable distribution with external cover, suitable for outdoor use. It has flexible compartmentation for the conduction and protection of electrical and communication cables. The base is perforated every 250mm. With the trunking are supplied, a retainer every 0. 5m and two junctions. These parts come pre-assembled. Length: 3m. Safety: mechanical (impact protection IK10), electrical (insulating material, IP4X mounted on the wall) and in case of fire (incandescent wire test at 960 Deg C, no flame propagator). The cover assembly is made under pressure (it is not necessary to slide to mount it). The retainer keeps the cables in place ensuring the fixing of the cover in the most demanding cases. The junctions mechanically join two sections of trunking guaranteeing its perfect alignment, facilitating the assembly and fixing of the bases on the surface. Both the trunking and the finishing elements can be painted. Mobile divider with front mounting. Colour: grey RAL 7035.
  • NEW DESIGN Unex trunking 60x110 in U23X

    Profile for cable distribution with external cover, suitable for outdoor use....
    View Product
    Profile for cable distribution with external cover, suitable for outdoor use. It has flexible compartmentation for the conduction and protection of electrical and communication cables. The base is perforated every 250mm. With the trunking are supplied, a retainer every 0. 5m and two junctions. These parts come pre-assembled. Length: 3m. Safety: mechanical (impact protection IK10), electrical (insulating material, IP4X mounted on the wall) and in case of fire (incandescent wire test at 960 Deg C, no flame propagator). The cover assembly is made under pressure (it is not necessary to slide to mount it). The retainer keeps the cables in place ensuring the fixing of the cover in the most demanding cases. The junctions mechanically join two sections of trunking guaranteeing its perfect alignment, facilitating the assembly and fixing of the bases on the surface. Both the trunking and the finishing elements can be painted. Mobile divider with front mounting. Colour: grey RAL 7035.
  • NEW DESIGN Unex trunking 60X90 in U23X

    Profile for cable distribution with external cover, suitable for outdoor use....
    View Product
    Profile for cable distribution with external cover, suitable for outdoor use. It has flexible compartmentation for the conduction and protection of electrical and communication cables. The base is perforated every 250mm. With the trunking are supplied, a retainer every 0. 5m and two junctions. These parts come pre-assembled. Length: 3m. Safety: mechanical (impact protection IK10), electrical (insulating material, IP4X mounted on the wall) and in case of fire (incandescent wire test at 960 Deg C, no flame propagator). The cover assembly is made under pressure (it is not necessary to slide to mount it). The retainer keeps the cables in place ensuring the fixing of the cover in the most demanding cases. The junctions mechanically join two sections of trunking guaranteeing its perfect alignment, facilitating the assembly and fixing of the bases on the surface. Both the trunking and the finishing elements can be painted. Mobile divider with front mounting. Colour: grey RAL 7035.
  • Unex trunking 60x60 in U23X

    For distribution. Suitable for outdoor use. Complete range with all...
    View Product
    For distribution. Suitable for outdoor use. Complete range with all necessary fittings, available in white and grey. Homogeneity with the rest of the installation's elements. 1 cable retainer every 0,5m is included. Length: 3m. Colour: grey. Safety: electrical (insulating material, IP4X mounted on wall); mechanical (protection against impacts IK08); and in front of fire (glow-wire test at 960 Deg C; non-flame propagator). Easy mounting. The cover is pressure mounted (no need to slide it). The cable retainer retains the cables and allows for independent access to each circuit. Homogeneity of colours between the trunking and the fittings. Can be painted. Removable divider, pressure mounted.
  • NEW DESIGN Unex trunking 40x60 in U23X

    Profile for cable distribution with external cover, suitable for outdoor use....
    View Product
    Profile for cable distribution with external cover, suitable for outdoor use. It has flexible compartmentation for the conduction and protection of electrical and communication cables. The base is perforated every 250mm. With the trunking are supplied, a retainer every 0. 5m and two junctions. These parts come pre-assembled. Length: 3m. Safety: mechanical (impact protection IK10), electrical (insulating material, IP4X mounted on the wall) and in case of fire (incandescent wire test at 960 Deg C, no flame propagator). The cover assembly is made under pressure (it is not necessary to slide to mount it). The retainer keeps the cables in place ensuring the fixing of the cover in the most demanding cases. The junctions mechanically join two sections of trunking guaranteeing its perfect alignment, facilitating the assembly and fixing of the bases on the surface. Both the trunking and the finishing elements can be painted. Mobile divider with front mounting. Colour: grey RAL 7035.
  • Unex trunking 40x40 in U23X

    For distribution. Suitable for outdoor use. Complete range with all...
    View Product
    For distribution. Suitable for outdoor use. Complete range with all necessary fittings, available in white and grey. Homogeneity with the rest of the installation's elements. 1 cable retainer every 0,5m is included. Length: 3m. Grey. Safety: electrical (insulating material, IP4X mounted on wall); mechanical (protection against impacts IK10); and in front of fire (glow-wire test at 960 Deg C; non-flame propagator). Easy mounting. The cover is pressure mounted (no need to slide it). The cable retainer retains the cables and allows for independent access to each circuit. Homogeneity of colours between the trunking and the fittings. Can be painted. Removable divider, pressure mounted.
  • Unex trunking 30x40 in U23X

    For distribution. Suitable for outdoor use. Complete range with all...
    View Product
    For distribution. Suitable for outdoor use. Complete range with all necessary fittings, available in white and grey. Homogeneity with the rest of the installation's elements. 1 cable retainer every 0,5m is included. Length: 3m. Grey. Safety: electrical (insulating material, IP4X mounted on wall); mechanical (protection against impacts IK08); and in front of fire (glow-wire test at 960 Deg C; non-flame propagator). Easy mounting. The cover is pressure mounted (no need to slide it). The cable retainer retains the cables and allows for independent access to each circuit. Homogeneity of colours between the trunking and the fittings. Can be painted. Removable divider, pressure mounted.
  • Unex mini trunking without divider 20x30 in U23X

    For distribution. Complete range with all necessary fittings, available in...
    View Product
    For distribution. Complete range with all necessary fittings, available in white and grey. Homogeneity with the rest of the installation's elements. Length: 2m. Grey. Safety: electrical (insulating material, IP4X); mechanical (protection against impacts IK07); and in front of fire (glow-wire test at 960 Deg C; non-flame propagator). Easy mounting. The cover is pressure mounted (no need to slide it). Homogeneity of colours between the mini trunking and the fittings. Can be painted.
