For sizes 40x60, 40x90 and 40x110, 2 pre-assembled junctions are supplied at one of the trunking's ends. These pieces mechanically join 2 trunking lengths guaranteeing a perfect alignment, facilitating the assembly and fixing of the bases of the trunking on the surface. Pressure, frontal mounting in any section of the trunking, allowing to join different trunking lengths. When using the junction, the cover will be well-aligned to the base. Suitable for suspended mountings and also for wall or ceiling mountings. For size 40x40, the junction is not supplied with the trunking and for its mounting it is necessary to use screws part no. 66809.

To retain cables. 1 cable retainer included every 0,5m. Insulating material. Easy mounting. Protection against mechanical damage IK08.

Retains and facilitates the laying of cables in the trunking. Ensures the fixing of the cover in the most demanding cases: impact resistance, vertical posts, inverted mountings, outdoors mountings etc. The trunking is supplied with a retainer every 0. 5m, fixed on the side of the trunking. If necessary, more retainers can be placed along the trunking. Quick assembly by simple pressure on the sides of the channel, even when the dividers are mounted on the trunkings base. Compatible with trunkings 40x60 in white and grey colour.

For sizes 60x90, 60x110 and 60x150, 2 pre-assembled junctions are supplied at one of the trunking's ends. These pieces mechanically join 2 trunking lengths guaranteeing a perfect alignment, facilitating the assembly and fixing of the bases of the trunking on the surface. Pressure, frontal mounting in any section of the trunking, allowing to join different trunking lengths. When using the junction, the cover will be well-aligned to the base. Suitable for suspended mountings and also for wall or ceiling mountings. For other trunkings of height 60, the junction is not supplied with the trunking and for its mounting it is necessary to use screws part no. 66809.

To retain cables. 1 cable retainer included every 0,5m. Insulating material. Easy mounting.

Retains and facilitates the laying of cables in the trunking. Ensures the fixing of the cover in the most demanding cases: impact resistance, vertical posts, inverted mountings, outdoors mountings etc. The trunking is supplied with a retainer every 0. 5m, fixed on the side of the trunking. If necessary, more retainers can be placed along the trunking. Quick assembly by simple pressure on the sides of the channel, even when the dividers are mounted on the trunkings base. Compatible with trunkings 40/60x90 in white and 60x90 in grey colour.

To retain cables. 1 cable retainer included every 0,5m. Insulating material. Easy mounting. Protection against mechanical damage IK08.

Retains and facilitates the laying of cables in the trunking. Ensures the fixing of the cover in the most demanding cases: impact resistance, vertical posts, inverted mountings, outdoors mountings etc. The trunking is supplied with a retainer every 0. 5m, fixed on the side of the trunking. If necessary, more retainers can be placed along the trunking. Quick assembly by simple pressure on the sides of the channel, even when the dividers are mounted on the trunkings base. Compatible with trunkings 40/60x110 in white colour and 60x110 in grey colour.

Retains and facilitates the laying of cables in the trunking. Ensures the fixing of the cover in the most demanding cases: impact resistance, vertical posts, inverted mountings, outdoors mountings etc. The trunking is supplied with a retainer every 0. 5m, fixed on the side of the trunking. If necessary, more retainers can be placed along the trunking. Quick assembly by simple pressure on the sides of the channel, even when the dividers are mounted on the trunkings base. Compatible with trunkings 60x150 in white and grey colour.

Retains and facilitates the laying of cables in the trunking. Ensures the fixing of the cover in the most demanding cases: impact resistance, vertical posts, inverted mountings, outdoors mountings etc. The trunking is supplied with a retainer every 0. 5m, fixed on the side of the trunking. If necessary, more retainers can be placed along the trunking. Quick assembly by simple pressure on the sides of the channel, even when the dividers are mounted on the trunkings base. Compatible with trunkings 60x130 in white colour.

Retains and facilitates the laying of cables in the trunking. Ensures the fixing of the cover in the most demanding cases: impact resistance, vertical posts, inverted mountings, outdoors mountings etc. The trunking is supplied with a retainer every 0. 5m, fixed on the side of the trunking. If necessary, more retainers can be placed along the trunking. Quick assembly by simple pressure on the sides of the channel, even when the dividers are mounted on the trunkings base. Compatible with trunkings 60x130 in white colour.
