LEDCL10-150AC-CW - LED 150W CANOPY LIGHT
LEDCL10-150AC-CW
This canopy light offers exceptional lm/W performance, reliability and design. The slim-line housing comes with Phillips Luxeon LED and Mean Well driver with prismatic acrylic lens.
-
Secure Payments are easier than ever! Eway’s payment solutions
-
Delivery Option’s, you choose from our list of delivery partners
-
Manufactures warranty on all Cableaway sold products.
This canopy light offers exceptional lm/W performance, reliability and design. The slim-line housing comes with Phillips Luxeon LED and Mean Well driver with prismatic acrylic lens. The standard model is 150W and delivers a huge 15,000 lumens. Designed for flush mounting or retrofitting into existing recessed troffer packs by using a converter gear plate.
APPLICATIONS
- Service stations
- Food processing
- Coolstores
- Under canopies
- Car parks
- Shopping malls
- Airports
TECHNICAL SPECIFICATIONS
|
Power Consumption
|
150W*
|
| Fixture Lumens | 14,962 |
|
Colour Temperature
|
5700K**
|
|
Colour Rendering (Ra)
|
>80q
|
|
Beam Angle
|
100°
|
|
LED
|
Phillips Luxeon 3030
|
|
IP Rating
|
IP65
|
| Driver | Meanwell CLG |
|
Input Power
|
100~277V AC, 50Hz
|
|
Luminaire Efficiency
|
99.10lm/W
|
|
Power Factor
|
0.9
|
|
Dimmable
|
No
|
| Operating Temperature | -20°C to +45°C |
| Operating Humidity | 20%-90% |
| Material | Aluminium, White Powder Coat, High Quality PMMA |
| Dimensions | 380x380x89mm |
| Cable | 1m 3 core cable |
*Other wattage options available on special order
**Other colour temperatures available on special order
